Android Premium Player - AP1-2111-11

Android Base Unit
  • Rockchip RK3588 Octa-core Processors with Mali G610 MP4 GPU.
  • 8K 60FPS video decoding and 2 HDMI 2.1 outputs and 1 DisplayPort.
  • WiFi 6, Bluetooth 5.0, and Gigabit Ethernet for seamless connectivity.

Download Datasheet

Model

AB1-2111-11

SOC

Rockchip RK3588 Octa-core processor Quad-core Cortex A76 and Quad-core Cortex A55

GPU

Mali G610 MP4 GPU

NPU

6 TOPS

Video decode

8K 10 bit decoder

RAM

LPDDR4X (8G)

ROM

eMMC (32G)

Storage expansion

SATA port

Video output

2x HDMI 2.1 port up to 8K@60Hz (please noted for 8K output can only show at one port)Display port 1.4USB-C port (DP protocol)

Video input

HDMI input

Video decoder

8K 60Hz H.265, VP9, AVS28K 30Hz H.264, AVC/MVC4K 60Hz, AVI, 1080P 60Hz MPEG-2, MPEG-1, VC-1, VP8

Video encoder

Real-time H.265/H.264 video encoding up to 8Kp30, also usable as a multi-channel encoder in parallel

Network

Gigabit Ethernet R45

Wi-Fi and Bluetooth

Dual band Wi-Fi 6 (2T2R) and Bluetooth 5.0AP6275P module External Wi-Fi antenna x2

Industrial ports

GPIO 5-pin x2Serial port x2

Power adaptor

12V 2Ah

USB

USB3.0 x1USB2.0 x2USB Type-C x1

Power button

ON/OFF

IR receiver

Support IR remote control

Dimension

150*110*30mm
